Battery Impact Testing Machine GT-I10

Battery Impact Testing Machine GT-I10

Battery impact tester tests the safety of the battery through different weights, different heights and different impact areas. The battery verifies as qualified on the condition of no flames or explosion after this heave impact test.



  • Item No :

    GT-I10
  • Order(MOQ) :

    1
  • Battery Impact Testing Machine GT-I10



    This Battery Impact Testing Machine is used for testing the battery safey performance.



    Application of Impact Tester for Battery



    The test sample battery should be placed on a flat surface, with a cross shaped rod with a diameter of 15.8 ± 0.2mm (5/8 inch) placed at the center of the sample. A 9.1kg or 10kg weight falls from a certain height (610mm or 1000mm) onto the sample. When cylindrical or square batteries undergo impact testing, their longitudinal axis should be parallel to the plane and perpendicular to the longitudinal axis of the steel column. The longest axis of the square battery is perpendicular to the steel column, and the largest surface is perpendicular to the impact direction.



    Each battery only undergoes one impact test. The battery is qualified if it does not catch fire or explode.



    Lithium Battery Impact Test Machine Standards



    GB/T 31485-2015, GB/T 31241-2022, UN38.3, IEC62133, UL1642:2012



    Battery impact testing equipment Key Specification



    Model

    GT-I10

    Drop weight

    9.1±0.1kg, 10kg±0.1kg

    Drop Height

    0-1000mm (commonly used test height 610 ± 25mm)

    Steel Rod

    Steel rod with a diameter of 15.8 ± 0.2mm

    Control method

    Touch screen control

    Precision

    ±5mm

    Max. Battery tested size

    200x200x200mm

    Impact mode

    Lift the falling ball to a certain height and release it.

    The falling ball falls freely in the vertical direction without tilting or shaking.

    Pressure Relief Vent

    The opening size is 200x200mm, located at the back of the box. When the sample explodes, the pressure relief port will pop open to release the pressure.

    Inner box dimensions

    490x520x1440mm

    Overall dimensions

    660x900x1720mm

    Power Supply

    1∮ AC220V
